Cantilever Arm Bracket
300–600 mm projection
Single-sided cantilever arm in 41 mm and 72 mm channel, used to carry pipework and cable tray off a wall or column.
- Material
- Q235B carbon steel, GB/T 700-2006
- Surface finish
- Electro-galvanised, hot-dip galvanised, epoxy coated, stainless steel
- Channel section
- 41 mm and 72 mm
Prices are quoted per project. Send the quantity and the support schedule for a quotation.
Product data
Technical information
The cantilever arm is a channel section with a welded or bolted end plate, fixed to a wall, column or embedded channel. Arms are listed in 41 mm and 72 mm channel with projections from 300 mm to 600 mm.
The arm carries the load in bending, so the projection and the channel section are selected together with the pipe weight and the support spacing.
- Material
- Q235B carbon steel, GB/T 700-2006
- Surface finish
- Electro-galvanised, hot-dip galvanised, epoxy coated, stainless steel
- Channel section
- 41 mm and 72 mm
- Projection
- 300, 400, 450, 500 and 600 mm
